encode, decode, monitor, video encoder, wireless,wired or wireless multimedia communication system,audio over the air # About NIMBUS INC The Ultimate Sourcefor Your Multimedia Communications Nimbus, inc. offers an innovative provider of wired or wireless multimedia communication system, esp and high quality audio over the air. The company's WiMi family of systems represents a series of near zero delay (within 10ms) H.264 HD encoder/decoder solution combining the ubiquity, flexibility and simplicity of near zero delay H.264 codec with the reliability and speed of Ethernet and IEEE802.11a/g/n Wi-Fi. Founded in November 2006, Nimbus, Inc. is privately-held and headquartered in Daejeon, s. Korea. It is led by a team of accomplished entrepreneurs and engineers with proven industry track records and over 100 years of combined technical experience in wired and wireless networking and broadband communications equipment. The company's mission is to be the leading global providerof wired/wireless full HD communication systems that will drive the next-generation high definition multimedia world. # Main Products 1. WiMi 4000 (Mulitmedia) 1) 1080i60/1080p60 HD encode/decode with H.264 Baseline Profile Level 4.2 - Supports both interlacing and progressive input streams 2) Very Low Encoding Latency, 40 ms - 40ms of encoding latency in 1080p60 HD - Total latency of encode-decode in 1080p60 HD: 80ms 3) Supportsboth TV &Monitor standards - DTV: 1920x1080p60, 1280x720p60, 720x480p60 - VESA: HD1080(1920x1080), UGA(1600x1200) reduced format, WSXGA+(1680x1050), SXGA(1280x1024), WXGA(1280x800), XGA(1024x768), SVGA(800x600), VGA(640x480) 4) Provides One-to-Many Multicasting Capability 5) Full HD Real-time Streaming Server over Internet (RTSP/RTP/UDP or MPEG-2 TS/UDP) - Maximum video encoding rate of RTSP/RTP/UDP streaming: 12 ~ 15Mbps - Maximum video encoding rate of MPEG-2 TS/UDP streaming: ~ 8Mbps - Maximum video encoding rate of MPEG-2 TS/UDP with LPCM audio streaming: ~ 5Mbps 6) Low-cost Solution of the Wireless HDMI: maximum distance of 450 m (1,500 feet) at line of sight (LOS) 7) Supports either High Quality 16-bit 48kHz audio or Bandwidth efficient G.711 Audio (64kbps or 128kbps) 8) Dimension of the Board and Enclosure - WiMi4000T/R enclosure (mm): 30 (H) x 184 (W) x 105 (D) - WiMi4000T/R board (mm): 20 (H) x 174 (W) x 87 (D) 2. WiMi 6000 (Multimedia) 1) 1080i60/1080p60 HD encode/decode with H.264 Baseline Profile Level 4.2 - Supports both interlacing and progressive input.streams of HD,1920 x 1080 at 60 frame per second 2) Very Low Encoding Latency, 40 ms - 40ms of encoding latency in 1080p60 HD - Total latency of encode-decode in 1080p60 HD: 80ms 3) Supports both TV &Monitor standards - DTV: 1920x1080p60, 1280x720p60, 720x480p60 - VESA: HD1080(1920x1080), WSXGA+(1680x1050), SXGA(1280x1024), WXGA(1280x800), XGA(1024x768), SVGA(800x600), VGA(640x480) 4) Provides One-to-Many Multicasting Capability 5) Full HD Real-time Streaming Server over Internet (RTSP/RTP/UDP or MPEG-2 TS/UDP) - Maximum video encoding rate of RTSP/RTP/UDP streaming: 25 ~ 30Mbps - Maximum video encoding rate of MPEG-2 TS/UDP streaming: ~ 15Mbps 6) High-end Solution of the Ethernet full HD with 30 Mbit/s of Video Encoding Rate 7) HD-SDI &3G-SDI Interface 8) Supports either High Quality 16-bit 48kHz linear PCM audio or Bandwidth efficient G.711 Audio (64kbps or 128kbps) 9) Dual Encoding Capability (option) 10) Dimension of the Board and Enclosure - WiMi6400T/R enclosure (mm): 30 (H) x 184 (W) x 100 (D) - WiMi6400T/R board (mm): 20 (H) x 175 (W) x 95 (D) 3. WiMi 6200 (Multimedia) 1) 1080i60/1080p60 HD encode/decode with H.264 Baseline Profile Level 4.2 - Supports both interlacing and progressive input.streams of HD,1920 x 1080 at 60 frame per second 2) Very Low Encoding Latency, 40 ms - 40ms of encoding latency in 1080p60 HD - Total latency of encode-decode in 1080p60 HD: 80ms 3) Supports TV standards - DTV: 1920x1080p60/i60/p50/i50/p30/p24, 1280x720p60/p50, 720x480i60, 720 x 576i50 4) Popular wireless: IEEE802.11n with maximum distance of 600 m (1,800 feet) at line of sight 5) Cost effective High-end Solution for the Wireless or Ethernet full HD with 30 Mbit/s of Video Encoding Rate 6) Provides One-to-Many Multicasting Capability 7) Full HD Live Streaming Server over Internet (RTSP/RTP/UDP or MPEG-2 TS/UDP) - Range of video encoding rate for RTSP/RTP/UDP streaming: 1 ~ 30Mbps - Range of video encoding rate for MPEG-2 TS/UDP streaming:1 ~ 15Mbps 8) Supports either High Quality 16-bit 48kHz linear PCM audio 9) Compact Size and Low Power Consumption - WiMi6200T/R enclosure (mm): 155 (H) x 30 (W) x 90 (D) - Power consumption: 10W ~ 12W - DC input range: 6V ~ 16V 4. PSE-2500 1) Ethernet over SONET/SDH (EoS) with VCAT, LCAS & GFP 2) mMSPP: 1 RU sized pizza-box located at customer site/central office 3) 4 x 155Mbps/622Mbps (STM-1/4) Optical Interfaces: 1+1 or UPSR Networking 4) Front panel access to all tributary signals 5) 2 user slots: Pluggable PDH cards with unit redundancy 6) More functions on SONET/SDH at half the price - Support HO VCAT/LCAS as well as LO VCAT/LCAS - Add/Drop Max. Protected STM-1(OC3)/STM-4(OC12), 16 x DS1/E1 and 2 x DS3/E3 - Eight electrical ports and eight SFP ports for 10/100 Ethernet - Enhanced traffic management function for 16 Ethernet ports 5. PSE-5000 1) Access MSPP: 3rd Gen. SONET/SDH: Ethernet over SONET/SDH 2) Capacity of Switching & Interface - TDM: 20 Gb/s of Switching Capacity with the granularity of 45M, 2M and 1.5M - Ethernet switching for EoS: 5 Gb/s - Full 2.5G VCAT bandwidth with Max. 24 Ethernet ports - Max. 128 x DS1/E1, 48 x DS3/E3 and 16 x OC-3 and 4 x OC-12 - Support BITS with external clock and derived clock with Stratum-3 clock & hold-over mode 3) Enhanced traffic management function 4) Trunk: Multiple 2.5Gb/s UPSR (SNCP Ring)/BLSR(MSSP Ring) 5) Tributary Interface: 622Mb/s, 155Mb/s, DS3, T1/E1, GbE, Fast Ethernet, RPR 6. Optical Transponder Network 1) 43G OUT-3 Line Card Solution - ATCA PICMG 3.1 compliant backboard interface - Supports OC-768, STM-256, G.709 OTU-3 - OIF, SFI-5 compliant interface - Supports 300pin MSA interface for 40G - Web based management # Video https://www.wevideo.com/hub#view/794598928 #Catalogue http://www.kompass.kr/img/catalogue/20180703012450_1.pdf
