Product
Inspection System
AccuVision Inspection System features
- AccuVision inspection systems, with easy to use standard software, are leading the way toward zero defect quality.
- FIS can be used to inspect Nuts,rods,washer fastener,O-ring,special parts.
- Optional cameras are available to check for internal threads and surface imperfections.
- Vision can be added to detect defects like missing internal threads, nylon ring presence, and missing crimp.
- This allows great detail of I.D. threads and the detection of very small defects like; Chips in threads, weld splatter, a single damaged thread, torn threads, reamed threads, short or missing thread(s).
- Windows based software makes part setup easy, and allows for part storage and retrieval.
- Developed software as per indian market requirement
- Run on Very High Speed FPGA based Motion Control Card and other controller
- User Friendly
- External and Internal diameter.
- Pitch and Thread numbers.
- Icomplete processed articles.
- Head crack.
- Head height.
- Broken pin.
- Thread and Slanted thread.
- Pin roundness.
- Length.
Price of the Product
Technical Details
No. of Camera - 4
Vision System - High resolution lanses and light source
Software - Accuvision Pro
Speed - 200 ~ 1000 pcs/min
Operating system - WINDOWS XP/7
Weight - 750 kgs
Accuracy - 0.010mm
Size - 2.1 X 1.4 X 1.9 Meter
